SPECIFICATIONS

1 - Detachable loading truck board with riveted cover in non-slip aluminium, without holes (Size 4750x2090 mm)

2 - Automatic blocking of the rear suspensions when the truck board slides out

3 - Fixed towing winch with cable guide/pressure rollers and manual engaging/disengaging of the drum. Towing capacity on 1st section 2200 kg. Wound wire rope 20 m, O 8 mm, with thumb or swivel hook

4 - Direct hydraulic lever controls for all functions, with enclosing panels and internal lighting

5 - Accelerator linked to the dashboard

6 - 2 front wheel chocks on the truck board.

7 - 2 rear holes with relative pulleys for side towing

8 - 2 belts with tensioners

9 - Rear leaf spring reinforcement

10 - 7-pin current socket, with the voltage of the vehicle

11 - Side lights

12 - Pre-arrangement for carrying motorcycles on the truck board

13 - Standard bolted cab guard

14 - Tool box

15 - Spare wheel support

16 - Rear mud guards with splash flaps

17 - Safety devices (CE marking)

18 - Two orange flashing beacons and two white work lights, on the cab

19 - Hot galvanisation of the equipment, painting of the cab guard and sides of the truck board

20 - Installation: TWG of 3.5 t

ACCESSORIES

1 - Aluminium guards on edges of truck board

2 - Side jerry can holder with two 10-L jerry cans

3 - Towing structure with ball hook, class 2

4 - Tow bar with interchangeable attachments

5 - Radio controller

6 - Movable embedded winch with load-bearing capacity of 2200 kg

7 - Electric socket and cables for starting vehicles - 12 V

8 - Trunk with 4 flashing beacons

9 - Extractable ball hook on the cab guard for towing caravans

10 - Motorcycle carrier on trolley

11 - Motorcycle carrier on truck board
