1 - Platform: Aluminium 1800 x 800 x h 1100 mm

2 - Platform rotation: Hydraulic 90° RH + 90° LH

3 - Platform levelling: Hydraulic

4 - Working boom: Double pantograph and end telescopic 3-section element

5 - Boom angle: -24°/+80°

6 - Upperstructure rotation: 370°

7 - Controls: Proportional electro-hydraulic

8 - Max. wind force: 12 m/s

9 - Max. manual force: 40 daN

10 - Capacity: 200 kg

11 - N° operators: 2

12 - Max. working height: 27.0 m

13 - Max. working boom extension: 13.70 m

14 - Outriggers: Vertical/tilted hydraulic type

15 - Outriggers minimum width: Front 2.65 m - Rear 2.66 m

16 - Minimum installation: TWG 7.5 T

1 - Proportional electrohydraulic controls mounted on cage with possibility of carrying out several manoeuvres simultaneously, duplicated on truck bed for emergency manoeuvres

2 - Outrigger controls on the truck board

3 - Control device of the load on the basket

4 - Blocking valves on all hydraulic units

5 - Interlocking safety device between outriggers and boom

6 - Manual pump for manoeuvring in the case of emergency

7 - Positioning of the people-carrier basket on the ground

8 - Floor in non-slip aluminium

9 - Anti-collision device between pantograph and cab

10 - Tool box under truck board

11 - 1 magnetic orange beacon

12 - Possibility of starting and stopping the engine from the basket and from the truck

13 - 220V socket on basket

14 - Basket ladder

15 - Mud guards with splash flaps on rear wheels

16 - Safety devices in compliance with Machine Directive (CE marking)

17 - Equipment painting
